Products Description
Specification:
Product Name:220-9106 K100 Excavator Welded Adapter LH
Weight: Welcome to inquire
Brand Name: Custom Logo
Material: High-spec alloy steel
Color: Yellow, or as required
Process: Investment casting / Lost wax casting/sand casting/forging
Packing: a Normal plywood case about 2tons per case
Tensile Strength ≥1400Rm-N/mm²
Shock ≥20J
Hardness: 48-52HRC
Certification: ISO9001:2008
Samples: Offer samples for free of charge, but freight collect.
Place of Origin: Zhejiang, China (Mainland)
CAT K100 Excavator Adapter Features & Benefits
Enhanced Reliability: These are the strongest, most robust adapters Caterpillar has ever produced, built for heavy-duty excavator bucket use.
Hammerless Installation: Quickest hammerless tip removal and installation with a 3/4 inch retainer lock, no special tools required.
Simplify Installation: Integrated retention components eliminate the need to search for loose pins or retainers during assembly.
Easy Retrofitting: Advansys adapters drop directly into the same space as standard K series adapters, for fast upgrading.
Simple Ordering: Use one single part number to order a full set of adapters and tips, reducing procurement complexity.
Optimized System Performance: Tapered tip sides reduce drag during digging, while optimized tip shapes place wear material where you need it most, improving productivity.
1. 220-9106 K100 Welded Adapter LH
Part Number: 220-9106 / 2209106
Type: Excavator Welded Adapter, Left Hand (LH)
Series: CAT K100 Series
Application: For Excavator Bucket Teeth System
Compatible with excavator models: Komatsu PC60-5, PC60-6, PC60-7, PC75-1, PC75-2, PC75-3, PC75UU, PC75UU-2, PC75UU-3; Yanmar V170, V175 and more.
2. 220-9104 K100 Adapter Centre
Part Number: 220-9104
Type: Centre Adapter
Series: CAT K100 Series
Application: For CAT Excavator Bucket
Compatible models: CAT325, CAT324, CAT323 Excavators
3. 232-2105 Right Adapter K100
Part Number: 232-2105
Type: Right Hand (RH) Adapter
Series: CAT K100 Series
Application: For Excavator Bucket
180-72-37 Excavator Rubber Track (J Track)
Width: 7.09 inches
Internal metal crossbars: 37
Pitch (center to center): 2.84 inches
Fits models: Hitachi EX7, EX8; Kobelco SK002, SK007, SK009; Komatsu PC03, PC09; Kubota K007, K008; Takeuchi TB007, TB108; Yanmar B07, B08
230-72-39 Excavator Rubber Track (J Track)
Width: 9.06 inches
Internal metal crossbars: 39
Pitch (center to center): 2.84 inches
Fits models: Ditch Witch HT25, JT1200, JT2511; Yanmar YB10R
230-72-47 Excavator Rubber Track (J Track)
Width: 9.06 inches
Internal metal crossbars: 47
Pitch (center to center): 2.84 inches
Fits models: Yanmar B17-2, B18EX, VIO15/2
300-52.5N-78 Excavator Rubber Track (J Track)
Width: 11.81 inches
Internal metal crossbars: 78
Pitch (center to center): 2.07 inches
Fits models: Hitachi EX20UR/UR3, EX25/I, EX27U/29U, EX12/1/2, EX15/1/2, EX15/U; John Deere 27ZTS; Kobelco SK25SR; Yanmar B27-2
300-55.5-78 Excavator Offset Rubber Track (J Track)
Width: 11.81 inches
Internal metal crossbars: 78
Pitch (center to center): 2.19 inches
Fits models: Yanmar B27, VIO27, VIO27.2
300-55.5-82 Excavator Offset Rubber Track (J Track)
Width: 11.81 inches
Internal metal crossbars: 82
Pitch (center to center): 2.19 inches
Fits models: Yanmar VIO35, VIO30, B37V
400-107-46 Excavator Rubber Track (J Track)
Width: 15.75 inches
Internal metal crossbars: 46
Pitch (center to center): 4.21 inches
Fits models: Komatsu PC40FR-1; Yanmar VIO40
400-75.5-74 Excavator Offset Rubber Track (J Track)
Width: 15.75 inches
Internal metal crossbars: 74
Pitch (center to center): 2.97 inches
Fits models: Komatsu PC40FR-2, FM40; Yanmar VIO57, VIO-55, B50-2B, VIO50-2
450-8IN-76 Excavator Rubber Track (J Track)
Width: 17.72 inches
Internal metal crossbars: 76
Pitch (center to center): 3.19 inches
Fits models: Komatsu PC60-5, PC60-6, PC60-7, PC75-1, PC75-2, PC75-3, PC75UU, PC75UU-2, PC75UU-3; Yanmar V170, V175
