Products Description
Specification:
Product Name:505-4131 A80 Right-Hand Non-impact Bucket Adapter
Weight: Welcome to inquire
Brand Name: Custom Logo
Material: High-spec alloy steel
Color: Yellow, or as required
Process: Investment casting / Lost wax casting/sand casting/forging
Packing: a Normal plywood case about 2tons per case
Tensile Strength ≥1400Rm-N/mm²
Shock ≥20J
Hardness: 48-52HRC
Certification: ISO9001:2008
Samples: Offer samples for free of charge, but freight collect.
Place of Origin: Zhejiang, China (Mainland)
Product Features & Specifications
Part Number: 505-4131 / 5054131
Series: Cat Advansys A80 Series
Type: Right-Hand (RH) Non-impact Bucket Adapter
For Main Edge: 36mm
Bevel Angle: 22.5°
Stop Angle: 5°
Application: Excavator buckets
Compatibility: Caterpillar genuine, OEM and new aftermarket excavator, dozer, grader, motorgrader, loader and backhoe parts
Cat Advansys System Benefits Summary
Improved ProductivityExclusive tip and adapter features result in the highest productivity Cat system.
Enhanced ReliabilityStrongest, most robust adapters Caterpillar has ever produced.
Hammerless InstallationQuickest hammerless tip removal and installation with a 3/4 inch retainer lock that requires no special tools.
Simplify InstallationIntegrated retention components mean no more searching for pins or retainers.
Simplify RetrofittingEasy upgrading because Advansys adapters drop into the same space as K series.
Simplify OrderingOne part number to order when changing a set of tips.
Cat Advansys System Performance
Exclusive performance features such as tapered tip sides offer less drag and higher productivity.
New and optimized tip shapes put wear material where you need it most.
Application Types
Heavy Abrasion – NEW!
Use in easy to penetrate high abrasive materials
Lower penetration ability
Heavy wear pad for long wear life
Heavy Penetration – NEW!
Use in hard to penetrate high abrasive materials
Very good penetration
Heavy wear pad for long wear life
Heavy Duty
Use in moderate abrasive materials
Good penetration
Single top self-sharpening cavity
General Purpose Loader
Use in low abrasive materials
Good penetration
Single top self-sharpening cavity
Coal
Use in low abrasive materials like coal seams
Use on loaders to produce a smoother floor
Penetration Plus
Use in hard to penetrate, moderate to high abrasive materials
Very good penetration
Stays sharp
Penetration
Use in hard to penetrate, low abrasive materials
Very good penetration
Stays sharp
Related Part Numbers
5054130 ADAPTER-CTR (A80 Two Strap Adapter Center)
5054069 ADAPTER-LH
5054068 ADAPTER-RH
5054067 ADAPTER-CTR
5054066 ADAPTER-CTR
5054065 ADAPTER-LH
5054155 ADAPTER-CTR
5054148 ADAPTER-LH
5054147 ADAPTER-RH
5054138 ADAPTER-LH
5054137 ADAPTER-RH
5054132 ADAPTER-LH
220-9086 Caterpillar K80 ADAPTER TIP LH
505-4012 / 5054012 A110 Advansys Caterpillar Digging Tip
505-3996 A90 Advansys Caterpillar Extra Duty Teeth
505-3982 A80 Advansys Caterpillar Loading Tip Extra Duty
220-9084 CAT K80 Bucket Adapter Two Strap
