Products Description
Specification:
Part No.:LA31FC40 VOE17491928 L220 L180 Bucket Flush Adapter
Weight: Welcome to inquire
Brand Name: Custom Logo
Replacement: Brand Volvo
Material: High-spec alloy steel
Color: Cat Yellow, or as required
Process: Investment casting / Lost wax casting/sand casting/forging
Packing: a Normal plywood case about 2tons per case
Tensile Strength ≥1400Rm-N/mm²
Shock ≥20J
Hardness: 48-52HRC
Certification: ISO9001:2008
Samples: Offer samples for free of charge, but freight collect.
Place of Origin: Zhejiang, China (Mainland)
| Model Designation | Part Number | Edge Thickness (mm) | Edge Angle (°) | Dimension A (mm) | Dimension B (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| LA31FC40 | VOE17491928 | 40 | 25 | 387 | 123 | 13 |
Engineered for precision grading and smooth material handling, the LA31FC40 Flush Adapter is the optimal replacement for Volvo and Samsung L180/L220 wheel loaders. Unlike standard adapters, this unit features a flush-mount design, providing a continuous smooth profile across the bucket edge. This eliminates material buildup and ensures a clean cut, making it indispensable for fine grading, leveling, and back-dragging applications.
Manufactured to meet rigorous aftermarket standards, this adapter serves as a direct bolt-on replacement for OEM Part Number VOE17491928, ensuring seamless integration without the need for bucket modification.
Key Technical Advantages
Streamlined Profile: The unique flush design reduces ground resistance and prevents debris accumulation, significantly improving工作效率 in finishing tasks.
Superior Metallurgy: Forged from high-grade alloy steel, specifically treated for high-impact environments.
Precision Fitment: Designed to match the original equipment geometry of the L180 and L220 series, guaranteeing stability and reducing wear on the bucket nose.
Material & Durability
We prioritize longevity in our casting process. The LA31FC40 adapter undergoes a specialized Quenching and Tempering (Q&T) heat treatment cycle. This process refines the grain structure of the steel, resulting in:
Surface Hardness: Consistently maintained between 48-52 HRC, offering exceptional resistance to abrasion and deformation.
Core Toughness: While the surface resists wear, the core retains high tensile strength to absorb shock loads, preventing catastrophic fractures in rocky conditions.
Why Choose Our LA31FC40 Adapter?
Optimized for Smooth Grading: The flush-mount design creates a continuous line across the bucket edge, essential for applications like slope finishing and clean-up work where a standard tooth profile would be too aggressive.
Superior Metallurgy: We utilize advanced casting techniques combined with high-manganese or high-chromium steel. This results in a component that resists abrasion and impact far better than standard carbon steel parts.
Exact Fitment: Designed to match the specifications of VOE17491928, ensuring a seamless weld-on installation for Volvo and Samsung L180/L220 series machines without modification.
Verified Durability: From the initial casting to the final heat treatment, every unit undergoes strict quality monitoring to ensure it meets the physical performance standards required for heavy-duty excavation.
