Products Description

The Caterpillar Ground Engaging Tool Dozer End Bits 8E9378 and 8E9379 are essential replacement components designed for Caterpillar bulldozers, specifically for models D4, D5, and D6. These end bits ensure superior performance and durability in various construction applications, providing an efficient cutting edge that maximizes productivity while minimizing downtime.

Part No.	8E9378, 8E9379
Dimensions	465 mm x 254 mm x 25 mm (6" x 3/4")
Weight	31KG
Replacement Brand	Caterpillar (CAT)
Machine Models	Track-Type Tractor, Bulldozer & Dozer
Product Type	Loader Blades
Material	C80/16Mn/30MnB (High-carbon and Boron steel)
Hardness	HB320-360 or HB440-480
Process	Heat Treatment
OEM	Custom Samples or Drawings
Type	Dozer Cutting Edges and Level Cut End Bit
Thickness Options	16 mm to 75 mm
Plow bolts	5J4773
Hex nuts	2J3506
Washers	5P8248
Color Options	yellow or customized colors available
Logo	"N" logo, "FHND" logo, Customized OEM logo
Production Processes	Coated Sand Casting, Forged Bucket Teeth Manufacturing, Precision Casting
Packaging	Normal plywood cases about 1tons per case Wrapped with Plastic Wrap for added protection
Delivery Time	35 days after order confirmation
Price term	FOB Ningbo
Payment terms	T/T, L/C, Other payment as discussion
Samples	Offer samples free of charge, but freight collect
Certification	ISO 9001:2015 and SGS certified.
Port	Ningbo, China
Place of Origin	Zhejiang, China

Enhanced Material Movement

Optimized for moving more material efficiently, reducing operational downtime.

Easy Installation

Standardized fittings and bolt specifications allow for straightforward replacements without the need for modifications.

Versatile Compatibility

Suitable for various brands of bulldozers, these end bits can be tailored to customer specifications or drawings.

Certified Quality

ISO9001:2015 certification ensures that each product meets stringent quality control measures.

Why choose FHND
Here Are Four Reasons Why You Choose Us

product-1-1

Product Features

Robust Design

Crafted for maximum wear protection, these end bits feature a thickness of 1 inch, width of 8 inches, and a length of 18.50 inches, making them ideal for heavy-duty applications.

Precision Fit

Designed to fit Caterpillar-style equipment with specific bolt hole spacing for easy installation, these bits accommodate standard plow bolts and nuts.

Heat Treatment Process

The end bits undergo quenching and tempering heat treatment, ensuring they meet international standards for mechanical properties, offering superior strength and performance.

FAQ

Q: Do you offer other spare parts apart from cutting edges?

A: Yes, we supply a wide range of spare parts, including chocky bars, breaker chisels, undercarriage components, and more

Q: Can I use these cutting edges for different types of machinery?

A: Yes, they are suitable for various construction and mining machines, including excavators and motor graders.

Q: What is the installation process for these end bits?

A: Installation involves using 4 plow bolts and 4 hex nuts, which fit the pre-drilled holes. Detailed instructions are typically provided with the product.

Q: Are these end bits available in colors other than yellow?

A: Yes, they can be produced in various colors such as red or black, or customized to meet specific customer requirements.
