Products Description
This is a Caterpillar style motor grader cutting edge and end bit, featuring a double bevel curved edge blade. Made from carbon and boron steel, this bolt-on motor grader edge-cutting overlay is a replacement CAT wear spare part, suitable for various grader applications.
Product Parameter
|
Part No. |
4T2233 |
|
Weight |
78KG |
|
Dimension |
2133*203*25 15*3/4" |
| Thickness | 1 |
| Width | 8 |
|
Holes |
15 |
|
Bolt |
4F7827 |
|
Nut |
2J3506 |
|
Washer |
5P8248 |
|
Tensile Strength |
≥1400Rm-N/mm² |
|
Shock Resistance |
≥20J |
|
Hardness |
HB280-320 or HB450-500 |
|
Material |
Carbon & Boron Steel |
| Machine Type | GRADER |
| Product Type | Grader Blades |
|
Color |
Yellow or as customer's request |
|
Logo |
"N" logo, "FHND" logo, Customized OEM logo |
|
Production Processes |
Coated Sand Casting, Forged Bucket Teeth Manufacturing, Precision Casting |
|
Compatible Equipment Models |
MOTOR GRADER 120G 12G 130G 140G Caterpillar |
|
Packaging |
Normal plywood cases about 1tons per case Wrapped with Plastic Wrap for added protection |
|
Delivery Time |
35 days after order confirmation |
|
Price term |
FOB Ningbo,FOBshanghai,etc |
|
Payment terms |
T/T, L/C, Other payment as discussion |
| Samples | Offer samples free of charge, but freight collect |
| Product certification |
ISO 9001:2015 |
| After-sales Service Provided | Online support |
Motor Grader Blades and End Bits Specifications
Model Options
Available as OEM parts or custom designs.
01
Components
Grader Blade: C80 high carbon steel and heat-treated 30MnB boron steel.
Grader End Bit: Heat-treated 16Mn or C45 and 30MnB boron steel.
02
Blade Types
Curved Grader Blade: Thickness from 13-25mm, width from 152-203mm.
Flat Grader Blade: Thickness from 16-75mm, width from 203-406mm.
Serrated Grader Blade: Available in both curved and flat configurations.
Additional Components: Includes casting ripper shanks and teeth.
03
Product Benefits
01
Rich Expertise
With a wealth of over twenty years in the field, we bring unparalleled knowledge and skill to our offerings.
02
Top-Quality Materials
Our blades undergo heat treatment and toughening, ensuring extended durability and optimal performance in various earthmoving, grading, and mining scenarios.
03
Direct from the Factory Pricing
Through direct manufacturing of our goods, we present competitive pricing, delivering cost-efficient solutions while maintaining high standards of quality.
FAQ
What types of designs are available for motor grader blades and end bits?
We offer both OEM part numbers and custom designs to suit various needs.
What is the lead time for custom orders?
Lead times vary depending on the specifics of the custom order. Please reach out to us for an estimated timeline based on your requirements.
What are the benefits of using a curved grader blade?
Curved blades provide improved performance, enhanced efficiency, reduced maintenance, and increased safety by ensuring consistent ground contact and better material control.
Are the grader blades compatible with all Caterpillar models?
Our blades are designed to be compatible with various Caterpillar machines and models, and they offer easy installation.
